STARTER MOTOR CB 500 X HONDA, ARROWHEAD 410-54263, 31200-MGZ-J81

Starter Motor - Arrowhead 410-54263

Compatibility:
Honda Model:

• Honda CB500X (2013-2018, 471cc)

Specifications:

• Type: Permanent Magnet Direct Drive (PMDD)
• Shaft OD: 11.9 mm
• B+ Stud: 6 mm x 1.0

Mounting Holes:

• Right Hand: 6.2 mm OD
• Left Hand: 7.0 mm OD
• Field Case Length: 61.1 mm
• Field Case Width: 61 mm OD
• Shaft Length: 21.6 mm + 3.9 mm Shoulder
• Length from DE Bearing to End of Shaft: 25 mm
• Overall Length (Approx.): 161 mm

Features:

• Meets or exceeds OEM quality.
• Direct OEM replacement with stock mounting locations.
• Designed to handle increased power loads.
• Best value for money.
• Made to OEM specifications, matching original equipment appearance.
• All electrical parts are 100% factory tested before shipping.
• Easy installation; consult a professional if unsure.
• Note: No Returns on Electrical Parts.

Cross Reference Numbers:

• 410-54263
