SHOCK FRONT POLARIS RANGER 7041784 BRONCO AU-04310

Part No. 29-569

FRONT SHOCK FITMENT

• POLARIS RANGER 500 1999
• POLARIS RANGER SERIES 10
• POLARIS RANGER SERIES 11
• POLARIS RANGER 2X4, 4X4 2003 - 2005 (SERIES 10/11)
• POLARIS RANGER 6X6 2005 RANGER 500 6X6 2003-2005 (SERIES
• POLARIS RANGER 6X6 700 EFI 2006-2008
• POLARIS UTV 2X4 2003
• POLARIS UTV 2X4/4X4/6X6 2004
• POLARIS UTV 4X4 2003

SPECIFICATIONS

• POSITION TOP HOLE I.D MM: 12.5 X 36 THREADED ROD
• TOP EYELET WIDTH MM: 12.5 X 36 THREADED ROD
• BOTTOM HOLE I.D MM: NA
• BOTTOM EYELET WIDTH MM: NA
• TUBE O.D MM: 41.5
• STROKE MM: 147
• SPRING OD MM: 96
• SPRING WIRE DIAMETER MM: 10.5
• SPRING RATE LBS/INCH: -
• SPRING RATE KG/MM: -
• CENTRE TO CENTRE MM: 493
• CENTRE TO CENTRE IN: 19 2/5

Cross reference numbers ONLY. POLAIRS 7041784,
