Wiseco
Wiseco Piston Ring Set 86.00 mm for Kawasaki KX500 1988–2004 3386TD
Wiseco Piston Ring Set 86.00 mm for Kawasaki KX500 1988–2004 3386TD
Regular price
£51.03 GBP
Regular price
Sale price
£51.03 GBP
Unit price
/
per
Taxes included.
Couldn't load pickup availability
Wiseco 3386TD is a piston ring set for a 86.00 mm bore.
Use with the compatible Wiseco piston or assembly configuration. The application list does not establish compatibility with an original equipment piston.
Wiseco catalogue applications
| Make | Model | Years |
|---|---|---|
| Kawasaki | KX500 | 1988–2004 |
| Yamaha | DT400 | 1975–1978 |
| Yamaha | MX400 | 1975–1976 |
| Yamaha | IT400 | 1976–1978 |
| Yamaha | YZ400 | 1977–1978 |
| Yamaha | IT465 | 1981–1982 |
| Yamaha | YZ465 | 1980–1981 |
| Suzuki | LT500 R Quadracer | 1987–1990 |
Specifications
- Manufacturer part number: 3386TD
- Bore Diameter: 86.00 MM
- Top Compression Ring Thickness: 1.2 MM
- Second Compression Ring Thickness: 1.2 MM
Manufacturer photograph for this reference. Packaging presentation may change.
