Wiseco Piston Pin 15.00 x 47.00 mm OD x length for Beta RR125 2018–2023 S632

Wiseco Piston Pin 15.00 x 47.00 mm OD x length for Beta RR125 2018–2023 S632

£23.67 GBP
£23.67 GBP
Sale Sold out
Taxes included.

Wiseco S632 is a piston pin with a 15.00 mm outer diameter.

Use with the compatible Wiseco piston or assembly configuration. The application list does not establish compatibility with an original equipment piston.

Wiseco catalogue applications

Make Model Years
Beta RR125 2018–2023
GasGas EC125 2000–2011
GasGas MC125 2000–2011
GasGas MC125 2021–2024
Honda CR125 R 1995–2007
Husaberg TE125 2012–2014
Husqvarna TC125 2014–2023
Husqvarna TE125 2014–2016
Husqvarna TX125 2017–2019
Husqvarna TE150 2017–2019
Husqvarna TE150i 2020–2024
Kawasaki KX125 2001–2008
KTM 125 SX 2001–2023
KTM 125 EXC 2009–2016
KTM 125 XC-W 2017–2019
KTM 144 SX 2008
KTM 150 SX 2009–2022
KTM 150 XC-W 2017–2019
KTM 150 EXC TPi 2020
KTM 150 EXC Tpi 2020–2024
KTM 150 XC-W Tpi 2021–2022
Suzuki RM125 2000–2011
Yamaha YZ125 1997–2004
Honda CRF230 F 2003–2019
Aprilia RS125/AF1 1985–2002
Honda RS125 1995–2003

Specifications

  • Manufacturer part number: S632
  • Piston Pin Outer Diameter: 15.00 MM
  • Piston Pin Inner Diameter: 9.50 MM
  • Piston Pin Length: 47.00 MM
  • Piston Pin Retainer Style: Wire Lock
  • Material: 5115

Application notes

  • KTM 125 SX 2001: Provide crankcase clearance for bores of 57 mm or above.
  • KTM 125 SX 2002–2006: Provide crankcase clearance for bores of 57 mm or above.
