Wiseco

Wiseco Piston Pin 15.00 x 47.00 mm OD x length for Yamaha YZ125 2005–2024 S668

Wiseco Piston Pin 15.00 x 47.00 mm OD x length for Yamaha YZ125 2005–2024 S668

£23.67 GBP
£23.67 GBP
Sale Sold out
Taxes included.

Wiseco S668 is a piston pin with a 15.00 mm outer diameter.

Use with the compatible Wiseco piston or assembly configuration. The application list does not establish compatibility with an original equipment piston.

Wiseco catalogue applications

Make Model Years
Yamaha YZ125 2005–2024
Yamaha YZ125 X 2020–2024
GasGas MC125 2021–2024
Honda CR125 R 1995–2007
Husaberg TE125 2012–2014
Husqvarna TC125 2014–2024
Husqvarna TE125 2014–2016
Husqvarna TX125 2017–2019
Husqvarna TE150 2017–2019
Husqvarna TE150i 2020
KTM 125 SX 2001–2024
KTM 125 EXC 2009–2016
KTM 125 XC-W 2017–2019
KTM 150 SX 2016–2022
KTM 150 XC-W 2017–2019
KTM 150 EXC TPi 2020
Kawasaki KX125 2001–2008
Suzuki RM125 2004–2011

Specifications

  • Manufacturer part number: S668
  • Piston Pin Outer Diameter: 15.00 MM
  • Piston Pin Inner Diameter: 10.50 MM
  • Piston Pin Length: 47.00 MM
  • Piston Pin Retainer Style: Wire Lock
  • Material: 5115

Application notes

  • Yamaha YZ125 2005–2021, Yamaha YZ125 X 2020–2022: Provide crankcase clearance for bores of 57 mm or above.
  • Yamaha YZ125 2005–2021, Yamaha YZ125 X 2020–2021: Provide crankcase clearance for bores of 57 mm or above.
View full details
