PISTON KIT VERTEX 52.5 A KAWASAKI KX 100 98-13, VERTEX 23614A

All Vertex Pistons Feature:
- Standard pistons and components are OEM replacements.
- Kits include piston, rings, wrist pin and circlips.
- All pistons are heat treated with a T-5 or T-6 hardening and tempering cycle.
- Replacement rings are sold individually.
- Made in Italy.
- Fitted in many oem bikes as STD.

SPECIFICATIONS

• BORE SIZE. 52.50mm [A 52.44mm]

Replacement Parts.

• Rings. 53010005250
• Pin. 715286
• Clips. 72050

Cross reference numbers ONLY.

• PISTON-ENGINE 13001-1503 13001-0123
• PIN-PISTON 13002-1018
• RING-SET-PISTON 13008-1107
• RING-SNAP 92033-1050 92033-0005

MODEL FITMENT

• KAWASAKI KX100 1998-2013
