PISTON KIT POLARIS 250 72.50, FORGED WOSSNER 8094D050

Piston Kit 72.50mm Bore 72.43 Wossner 8094D050 (+0.50)

POLARIS
Trail boss 1985 - 2005,
Scrambler 1985 - 2005,
Trail blazer 250 1985 - 2005,

• Wossner forged pistons are superior in strength and design.
• Engineered to provide the best possible path for combustion chamber heat transfer to cylinder walls.
• Elliptically designed to provide a more uniform bearing surface under piston heat expansion, eliminating localized pressure and distributing thrust loads more evenly, thereby preventing piston collapse.
• Made in Germany.

Part No. 56-W163_050.WO (oro2u.com)
Wossner Piston Polaris Trail (PN# 8094D050)
Lock P/N CW18
Pin P/N WP033
Ring Set P/N RSB7250 x 2

Display (cm3) 244
Hub stroke (mm) 60.00
Clearance (mm) 0.07
Wossner compression Ratio: 2 stroke
OEM Compression ratio: 2 stroke
Dome volume (cm3) Flat
Compression height (mm) 38.00
Theorectical weight (G)
