PISTON KIT HUSKY 90-97 350 84, WOSSNER 8510DB HUSQVARNA

Piston Kit 84.00mm Bore 83.94 Wossner 8510DB (+0.01)

Husqvarna

• TE 350: 1990 - 1997

Features:

• Wossner forged pistons are superior in strength and design.
• Engineered to provide the best possible path for combustion chamber heat transfer to cylinder walls.
• Elliptically designed to provide a more uniform bearing surface under piston heat expansion, eliminating localized pressure and distributing thrust loads more evenly, thereby preventing piston collapse.
• Made in Germany.

• Wossner Piston: Husqvarna TE350 84.01 (PN# 8510DB)
• Lock P/N: CW20
• Pin P/N: WP029
• Ring Set P/N: 840XSY

Specifications:

• Display (cm3): 349
• Hub stroke (mm): 63.00
• Clearance (mm): 0.06
• Wossner compression Ratio: OEM
• OEM Compression ratio: 10.20:1
• Dome volume (cm3): +3.60
• Compression height (mm): 28.00
