PISTON KIT HSQ 250 74-84 71.00, WOSSNER 8004D150 HUSQVARNA

Piston kit 71.00mm Bore 70.94 Wossner 8004D150 (+1.50)

HUSQVARNA
CR250 1974 - 1984,
WR250 1974 - 1984,
XR250 1974 - 1984,

• Wossner forged pistons are superior in strength and design.
• Engineered to provide the best possible path for combustion chamber heat transfer to cylinder walls.
• Elliptically designed to provide a more uniform bearing surface under piston heat expansion, eliminating localized pressure and distributing thrust loads more evenly, thereby preventing piston collapse.
• Made in Germany

Part No. 56-W218+150.WO (oro2u.com)
Wossner Piston Husqvarna CR250 71.00 mm Bore (PN# 8004D150)
Lock P/N CW18
Pin P/N WP033
Ring Set P/N RSB7100

Display (cm3) 510
Hub stroke (mm) 65.80
Clearance (mm) 0.06
Wossner compression Ratio: 2 stroke
OEM Compression ratio: 2 stroke
Dome volume (cm3)
Compression height (mm) 32.00
Theorectical weight (G)

S/SEED FROM 56-W137.WOSSNER TO 56-W218+150.W0
