PISTON KIT 91-01 RM80 49.50, WOSSNER 8270D200 SUZUKI MX

Piston kit 49.50mm Bore 49.45 Wossner 8270D200 (+2.00)

SUZUKI
RM80 1991 - 2001, (US BORE)

• Wossner forged pistons are superior in strength and design.
• Engineered to provide the best possible path for combustion chamber heat transfer to cylinder walls.
• Elliptically designed to provide a more uniform bearing surface under piston heat expansion, eliminating localized pressure and distributing thrust loads more evenly, thereby preventing piston collapse.
• Made in Germany.

Part No. 56-W645+P8.WO (oro2u.com)
Wossner Piston Kawasaki KX80 49.50 mm Bore (PN# 8270D200)
Lock P/N CW14
Pin P/N WP058
Ring Set P/N RSB4950

Display (cm3) 82
Hub stroke (mm) 46.80
Clearance (mm) 0.05
Wossner compression Ratio: 2 stroke
OEM Compression ratio: 2 stroke
Dome volume (cm3)
Compression height (mm) 27.00
Theorectical weight (G)
