PISTON KIT 91-01 RM80 46.50, WOSSNER 8231DA SUZUKI MX

Piston kit 46.50mm Bore 46.45 Wossner 8231DA (STD)

SUZUKI
RM80 1991 - 2001, (International bore)

• Wossner forged pistons are superior in strength and design.
• Engineered to provide the best possible path for combustion chamber heat transfer to cylinder walls.
• Elliptically designed to provide a more uniform bearing surface under piston heat expansion, eliminating localized pressure and distributing thrust loads more evenly, thereby preventing piston collapse.
• Made in Germany.

Part No. 56-W670+000.WO (oro2u.com)
Wossner Piston Suzuki RM80 46.5 mm Bore (PN# 8231DA)
Lock P/N CW14
Pin P/N WP058
Ring Set P/N RSB4650

Display (cm3) 82
Hub stroke (mm) 46.80
Clearance (mm) 0.05
Wossner compression Ratio: 2 stroke
OEM Compression ratio: 2 stroke
Dome volume (cm3)
Compression height (mm) 27.00
Theorectical weight (G)

1991 Suzuki RM 80 1992 Suzuki RM 80 1993 Suzuki RM 80 1994 Suzuki RM 80 1995 Suzuki RM 80 1996 Suzuki RM 80 1997 Suzuki RM 80 1998 Suzuki RM 80

1999 Suzuki RM 80 2000 Suzuki RM 80 2001 Suzuki RM 80
