PISTON KIT 90-91 KX250 67.40 A, WOSSNER 8109DA KAWASAKI MX 13001-1345

Piston kit 67.40mm Bore 67.34 Wossner 8109DA (STD)

KAWASAKI
KX250 1990 - 1994,
KDX250 1990 - 1994,

• Wossner forged pistons are superior in strength and design.
• Engineered to provide the best possible path for combustion chamber heat transfer to cylinder walls.
• Elliptically designed to provide a more uniform bearing surface under piston heat expansion, eliminating localized pressure and distributing thrust loads more evenly, thereby preventing piston collapse.
• Made in Germany.

Part No. 56-W607+00A.WO (oro2u.com)
Wossner Piston Kawasaki KX250 67.4 mm Bore (PN# 8109DA)
Lock P/N CW18
Pin P/N WP033
Ring Set P/N RSB6740 X 2
Rod P/N P2022

Display (cm3) 250
Hub stroke (mm) 70.00
Clearance (mm) 0.06
Wossner compression Ratio: 2 stroke
OEM Compression ratio: 2 stroke
Dome volume (cm3)
Compression height (mm) 37.00
Theorectical weight (G)

Cross reference numbers ONLY.
13001-1345, 607M06740

1990 Kawasaki KX 250 1991 Kawasaki KDX 250 1991 Kawasaki KX 250 1992 Kawasaki KDX 250 1993 Kawasaki KDX 250 1994 Kawasaki KDX 250
