PISTON KIT 89-95 RM250 67.00 B, WOSSNER 8022DB SUZUKI MX

Suzuki
RM250 1989-1995,
RMX250 1993-1995,

• Wossner forged pistons are superior in strength and design.
• Engineered to provide the best possible path for combustion chamber heat transfer to cylinder walls.
• Elliptically designed to provide a more uniform bearing surface under piston heat expansion, eliminating localized pressure and distributing thrust loads more evenly, thereby preventing piston collapse.
• Made in Germany.


Part No. 56-W642.00B.WO (phoenixmotos.com)
Lock P/N CW18
Pin P/N WP033
Ring Set P/N RSB6700 x 2

Display (cm3) 246
Hub stroke (mm) 70.80
Clearance (mm) 0.06
Wossner compression Ratio: 2 stroke
OEM Compression ratio: 2 stroke
Dome volume (cm3)
Compression height (mm) 37.00
Theorectical weight (G)

Cross reference numbers ONLY.
PISTON 12110-28C11-0F0, 12110-29E20-0F0 , RING, PISTON 12141-41600, 12141-41620, PIN, PISTON 12151-28C00, 12151-37F00 , CIRCLIP 09381-18002,

1993 Suzuki RM 250
1993 Suzuki RMX 250
1994 Suzuki RM 250
1994 Suzuki RMX 250
1995 Suzuki RM 250
1995 Suzuki RMX 250
