PISTON KIT 89-90 RM80 49.00, WOSSNER 8191D150 SUZUKI MX

SUZUKI
RM80 1989 - 1990,

• Wossner forged pistons are superior in strength and design.
• Engineered to provide the best possible path for combustion chamber heat transfer to cylinder walls.
• Elliptically designed to provide a more uniform bearing surface under piston heat expansion, eliminating localized pressure and distributing thrust loads more evenly, thereby preventing piston collapse.
• Made in Germany.

Part No. 56-W579+150.WO (phoenixmotos.com)
Wossner Piston Suzuki RM80 49 mm Bore (PN# 8191D150)
Lock P/N CW14
Pin P/N WP058
Ring Set P/N RSB4900

Display (cm3) 82
Hub stroke (mm) 46.80
Clearance (mm) 0.05
Wossner compression Ratio: 2 stroke
OEM Compression ratio: 2 stroke
Dome volume (cm3)
Compression height (mm) 27.00
Theorectical weight (G)
