PISTON KIT 88-92 YZ80 48.50, WOSSNER 8187D050 YAMAHA MX

YAMAHA
YZ80 1988 - 1992,

• Wossner forged pistons are superior in strength and design.
• Engineered to provide the best possible path for combustion chamber heat transfer to cylinder walls.
• Elliptically designed to provide a more uniform bearing surface under piston heat expansion, eliminating localized pressure and distributing thrust loads more evenly, thereby preventing piston collapse.
• Made in Germany.

Part No. 56-W569+050.WO (phoenixmotos.com)
Wossner Piston Yamaha YZ80 48 mm Bore (PN# 8187D050)
Lock P/N CW12
Pin P/N WP091
Ring Set P/N RSB4850

Display (cm3) 82
Hub stroke (mm) 45.60
Clearance (mm) 0.05
Wossner compression Ratio: 2 stroke
OEM Compression ratio: 2 stroke
Dome volume (cm3)
Compression height (mm) 27.00
Theorectical weight (G)
