PISTON KIT 88-91 YZ250 68.00, WOSSNER 8134DA YAMAHA MX

Piston kit 68mm Bore 67.94 Wossner 8134DA (STD)

YAMAHA
YZ250 1988 - 1991,
WR250 1988 - 1991,

• Wossner forged pistons are superior in strength and design.
• Engineered to provide the best possible path for combustion chamber heat transfer to cylinder walls.
• Elliptically designed to provide a more uniform bearing surface under piston heat expansion, eliminating localized pressure and distributing thrust loads more evenly, thereby preventing piston collapse.
• Made in Germany.

Wossner Piston Yamaha YZ250 68 mm Bore (PN# 8134DA)
Lock P/N CW18
Pin P/N WP033
Ring Set P/N RSB6800 X 2

Display (cm3) 246
Hub stroke (mm) 68.00
Clearance (mm) 0.06
Wossner compression Ratio: 2 stroke
OEM Compression ratio: 2 stroke
Dome volume (cm3)
Compression height (mm) 36.00
Theorectical weight (G)

1988 Yamaha WR 250 1988 Yamaha YZ Base 1989 Yamaha WR 250 1989 Yamaha YZ Base 1990 Yamaha WR 250 1990 Yamaha YZ Base 1991 Yamaha WR 250 1991 Yamaha YZ Base
