PISTON KIT 88-07 YFS200 67.00, WOSSNER 8101D100 YAMAHA ATV

YAMAHA (ATV)
YFS200 Blaster 1988 - 2006,

• Wossner forged pistons are superior in strength and design.
• Engineered to provide the best possible path for combustion chamber heat transfer to cylinder walls.
• Elliptically designed to provide a more uniform bearing surface under piston heat expansion, eliminating localized pressure and distributing thrust loads more evenly, thereby preventing piston collapse.
• Made in Germany.


Part No. 56-W573+100.WO (phoenixmotos.com)
Wossner Piston Yamaha YFS200 Blaster 67 mm Bore (PN# 8101D100)
Lock P/N CW16
Pin P/N WP027
Ring Set P/N RSB6700 x 2
Rod P/N P2030

Display (cm3) 199
Hub stroke (mm) 57.00
Clearance (mm) 0.06
Wossner compression Ratio: 2 stroke
OEM Compression ratio: 2 stroke
Dome volume (cm3)
Compression height (mm) 29.90
Theorectical weight (G)
