PISTON KIT 88-00 KX80 48.00 A, WOSSNER 8197DA KAWASAKI MX 13001-1259

Piston kit 48mm Bore 47.95 Wossner 8197DA (STD)

KAWASAKI
KX80 1988 - 2000, (US BORE)

• Wossner forged pistons are superior in strength and design.
• Engineered to provide the best possible path for combustion chamber heat transfer to cylinder walls.
• Elliptically designed to provide a more uniform bearing surface under piston heat expansion, eliminating localized pressure and distributing thrust loads more evenly, thereby preventing piston collapse.
• Made in Germany.

Part No. 56-W644+A.WO (oro2u.com)
Wossner Piston Kawasaki KX80 48 mm Bore (PN# 8197DA)
Lock P/N CW14
Pin P/N WP058
Ring Set P/N RSB4800

Display (cm3) 80
Hub stroke (mm) 45.80
Clearance (mm) 0.05
Wossner compression Ratio: 2 stroke
OEM Compression ratio: 2 stroke
Dome volume (cm3)
Compression height (mm) 26.00
Theorectical weight (G)

Cross reference numbers ONLY.
13001-1259, 644M04800

1994 Kawasaki KX 80 1995 Kawasaki KX 80 1996 Kawasaki KX 80 1997 Kawasaki KX 80 1998 Kawasaki KX 80 1999 Kawasaki KX 80 2000 Kawasaki KX 80
