PISTON KIT 88-00 KX80 47.00 A, WOSSNER 8234DA KAWASAKI MX

KAWASAKI
KX80 1988 - 2000,

• Wossner forged pistons are superior in strength and design.
• Engineered to provide the best possible path for combustion chamber heat transfer to cylinder walls.
• Elliptically designed to provide a more uniform bearing surface under piston heat expansion, eliminating localized pressure and distributing thrust loads more evenly, thereby preventing piston collapse.
• Made in Germany.

Part No. 56-W669.A.WO (phoenixmotos.com)
Wossner Piston Kawasaki KX80 47mm Bore (PN# 8234DA)
Lock P/N CW14
Pin P/N WP058
Ring Set P/N RSB4700
Rod P/N P2005

Display (cm3) 79
Hub stroke (mm) 45.80
Clearance (mm) 0.05
Wossner compression Ratio: 2 stroke
OEM Compression ratio: 2 stroke
Dome volume (cm3)
Compression height (mm) 26.00
Theorectical weight (G)

Cross reference numbers ONLY.
669M04700
