PISTON KIT 87-90 TRX250 68.00, WOSSNER 8189D200 HONDA ATV

HONDA (ATV)
ATC250R 1987 -1990,
TRX250R 1987 - 1990,

• Wossner forged pistons are superior in strength and design.
• Engineered to provide the best possible path for combustion chamber heat transfer to cylinder walls.
• Elliptically designed to provide a more uniform bearing surface under piston heat expansion, eliminating localized pressure and distributing thrust loads more evenly, thereby preventing piston collapse.
• Made in Germany

Part No. 56-W562.P8.WO (phoenixmotos.com)
Wossner Piston Honda ATC250R 68 mm Bore (PN# 8189D200)
Lock P/N CW18
Pin P/N WP033
Ring Set P/N RSB6800 X 2

Display (cm3) 246
Hub stroke (mm) 72.00
Clearance (mm) 0.06
Wossner compression Ratio: 2 stroke
OEM Compression ratio: 2 stroke
Dome volume (cm3)
Compression height (mm) 33.00
Theorectical weight (G)

1987 Honda ATC 250R - 1987 Honda TRX 250 R - 1988 Honda ATC 250R - 1988 Honda TRX 250 R - 1989 Honda ATC 250R - 1989 Honda TRX 250 R

- 1990 Honda ATC 250R - 1990 Honda TRX 250 R
