PISTON KIT 87-90 LT500R 87.50, WOSSNER 8260D150 SUZUKI ATV

Piston kit 87.50mm Bore 87.41 Wossner 8260D150 (+1.50)

SUZUKI (ATV)
LT500R 1987 - 1990,

• Wossner forged pistons are superior in strength and design.
• Engineered to provide the best possible path for combustion chamber heat transfer to cylinder walls.
• Elliptically designed to provide a more uniform bearing surface under piston heat expansion, eliminating localized pressure and distributing thrust loads more evenly, thereby preventing piston collapse.
• Made in Germany

Part No. 56-W561+1.50.WO (oro2u.com)
Wossner Piston Suzuki LT500R 87-90 87.50mm Bore
(PN# 8260D150)
Lock P/N CW18
Ring Set P/N RSC8750 X 2

Display (cm3) 498
Hub stroke (mm) 86.00
Clearance (mm) 0.09
Wossner compression Ratio: 2 stroke
OEM Compression ratio: 2 stroke
Dome volume (cm3)
Compression height (mm) 45.00
Theorectical weight (G)
