PISTON KIT 86-87 RM80 48.00, WOSSNER 8227D050 SUZUKI MX

Piston kit 48mm Bore 47.95 Wossner 8227D050 (+0.50)

SUZUKI
RM80 1986 - 1987,

• Wossner forged pistons are superior in strength and design.
• Engineered to provide the best possible path for combustion chamber heat transfer to cylinder walls.
• Elliptically designed to provide a more uniform bearing surface under piston heat expansion, eliminating localized pressure and distributing thrust loads more evenly, thereby preventing piston collapse.
• Made in Germany

Part No. 56-W542+050.WO (oro2u.com)
Wossner Piston Suzuki RM80 48 mm Bore (PN# 8227D050)
Lock P/N CW14
Pin P/N WP058
Ring Set P/N RSB4800

Display (cm3) 80
Hub stroke (mm) 46.80
Clearance (mm) 0.05
Wossner compression Ratio: 2 stroke
OEM Compression ratio: 2 stroke
Dome volume (cm3)
Compression height (mm) 27.00
Theorectical weight (G)
