PISTON KIT 85-86 RM125 54.00, WOSSNER 8123DA SUZUKI MX 12101-14850

SUZUKI
RM125 1985 - 1986,

• Wossner forged pistons are superior in strength and design.
• Engineered to provide the best possible path for combustion chamber heat transfer to cylinder walls.
• Elliptically designed to provide a more uniform bearing surface under piston heat expansion, eliminating localized pressure and distributing thrust loads more evenly, thereby preventing piston collapse.
• Made in Germany

Part No. 56-W519+000.WO (phoenixmotos.com)
Wossner Piston Suzuki RM125 54 mm Bore (PN# 8123DA)
Lock P/N CW14
Pin P/N WP025
Ring Set P/N RSB5400 X 2

Display (cm3) 123
Hub stroke (mm) 54.00
Clearance (mm) 0.06
Wossner compression Ratio: 2 stroke
OEM Compression ratio: 2 stroke
Dome volume (cm3)
Compression height (mm) 29.50
Theorectical weight (G)

Cross reference numbers ONLY.
12101-14850, 519M05400
