PISTON KIT 83-88 500 88.00mm, WOSSNER 8037D200 HUSQVARNA

Piston kit 88.00mm Bore 87.22 Wossner 8037D200 (+2.00)

Husqvarna
CR 500 1983 - 1987,

• Wossner forged pistons are superior in strength and design.
• Engineered to provide the best possible path for combustion chamber heat transfer to cylinder walls.
• Elliptically designed to provide a more uniform bearing surface under piston heat expansion, eliminating localized pressure and distributing thrust loads more evenly, thereby preventing piston collapse.
• Made in Germany.

PART NO. 56-W091+2.00 (oro2u.com)
Wossner Piston Husqvarna CR500 88 mm Bore (PN# 8037D200)
Lock P/N CW20
Pin P/N WP086
Ring Set P/N RSC8800

Display (cm3) 500
Hub stroke (mm) 84.00
Clearance (mm) 0.08
Wossner compression Ratio: 2 stroke
OEM Compression ratio: 2 stroke
Dome volume (cm3) -
Compression height (mm) 42.00
Theorectical weight (G)
