PISTON KIT 80-82 CR80 50.00, WOSSNER 8277D050 HONDA

Piston kit 50mm Bore 49.95 Wossner 8277D050 (+0.50)

HONDA
CR80R 1980-1982,

• Wossner forged pistons are superior in strength and design.
• Engineered to provide the best possible path for combustion chamber heat transfer to cylinder walls.
• Elliptically designed to provide a more uniform bearing surface under piston heat expansion, eliminating localized pressure and distributing thrust loads more evenly, thereby preventing piston collapse.
• Made in Germany

PART NO. 56-W450+P2.WO (oro2u.com)
WOSSNER PISTON KIT SIZE 49.95mm 8277D050
Lock P/N CW12
Pin P/N WP091
Ring Set P/N RSB5000 X 2

Display (cm3) 79
Hub stroke (mm) 41.40
Clearance (mm) 0.05
Wossner compression Ratio: 2 stroke
OEM Compression ratio: 2 stroke
Dome volume (cm3)
Compression height (mm) 27.00
Theorectical weight (G)
