PISTON KIT 1987 RM125 54.50, WOSSNER 8122D050 SUZUKI MX 12110-01B38-0F0

SUZUKI
RM125 1987,

• Wossner forged pistons are superior in strength and design.
• Engineered to provide the best possible path for combustion chamber heat transfer to cylinder walls.
• Elliptically designed to provide a more uniform bearing surface under piston heat expansion, eliminating localized pressure and distributing thrust loads more evenly, thereby preventing piston collapse.
• Made in Germany

Part No. 56-W557+050_WO (phoenixmotos.com)
Wossner 54.50mm Piston kit (PN# 8129DA) Application SUZUKI RM125 1987
Lock P/N CW14
Pin P/N WP025
Ring Set P/N RSB5450 x 2

Display (cm3) 123
Hub stroke (mm) 70.00
Clearance (mm) 0.06
Wossner compression Ratio: 2 stroke
OEM Compression ratio: 2 stroke
Dome volume (cm3)
Compression height (mm) 37.00
Theorectical weight (G)

Cross reference numbers ONLY.
12110-01B38-0F0
