PISTON KIT 1979 CR125 57.50, FORGED WOSSNER 8150D150

Piston kit 57.50mm Bore 57.44 Wossner 8150D150 (+1.50)

HONDA
CR125 1979,

• Wossner forged pistons are superior in strength and design.
• Engineered to provide the best possible path for combustion chamber heat transfer to cylinder walls.
• Elliptically designed to provide a more uniform bearing surface under piston heat expansion, eliminating localized pressure and distributing thrust loads more evenly, thereby preventing piston collapse.
• Made in Germany

Part No. 56-W430+P6.WO (oro2u.com)
Wossner Piston Honda CR125 57.5 mm Bore (PN# 8150D150)
Lock P/N CW14
Pin P/N WP025
Ring Set P/N RSB5750 x 2

Display (cm3) 123
Hub stroke (mm) 70.00
Clearance (mm) 0.07
Wossner compression Ratio: 2 stroke
OEM Compression ratio: 2 stroke
Dome volume (cm3)
Compression height (mm) 38.00
Theorectical weight (G)
