PISTON KIT 1979 CR125 56.25, FORGED WOSSNER 8150D025

Piston kit 56.25mm Bore 56.19 Wossner 8150D025 (+0.25)

HONDA
CR125 1979,

• Wossner forged pistons are superior in strength and design.
• Engineered to provide the best possible path for combustion chamber heat transfer to cylinder walls.
• Elliptically designed to provide a more uniform bearing surface under piston heat expansion, eliminating localized pressure and distributing thrust loads more evenly, thereby preventing piston collapse.
• Made in Germany

Part No. 56-W430+P1.WO (oro2u.com)
Wossner Piston Honda CR125 56.25 mm Bore (PN# 8150D025)
Lock P/N CW14
Pin P/N WP025
Ring Set P/N RSB5625 x 2

Display (cm3) 123
Hub stroke (mm) 70.00
Clearance (mm) 0.07
Wossner compression Ratio: 2 stroke
OEM Compression ratio: 2 stroke
Dome volume (cm3)
Compression height (mm) 38.00
Theorectical weight (G)
