PISTON KIT 13-17 RMZ450 96 HC, WOSSNER 8887DC SUZUKI

This Wossner forged piston kit, part number 8887DC, features a 96.02mm bore with an actual bore size of 95.98mm (+0.02mm oversize). It is specifically designed for high-compression applications in Suzuki RM-Z450 models from 2013 to 2017. Manufactured in Germany, the piston is built for high-performance use, offering increased compression over OEM specifications, and features an elliptical design to ensure even load distribution and superior heat transfer.

Features

• Forged piston for enhanced strength and durability
• High compression design for improved performance
• Elliptical profile for balanced expansion and reduced localized stress
• Engineered for optimal heat transfer from combustion to cylinder walls
• Made in Germany
• Direct OEM replacement
• Easy to install; professional installation recommended if unsure

Specifications

• Bore Size: 96.02mm
• Actual Bore: 95.98mm
• Displacement: 449cm³
• Stroke: 62.10mm
• Clearance: 0.04mm
• Dome Volume: -0.40cm³
• Wossner Compression Ratio: 13.50:1
• OEM Compression Ratio: 12.50:1
• Compression Height: 22.90mm

Cross-Reference OEM Part Numbers

• CW19 (Lock)
• WP071 (Pin)
• 960ADS-2 (Ring Set)
• P4013 (Rod)
• MB83C072C (Main Bearing Right)
• MB830053-4 (Main Bearing Left)

Vehicle Fitments

• RM-Z450 (2013–2017)
