PISTON KIT 11-14 TE250 HUSAB, HUSABERG WOSSNER 8272DB

Wossner 66.41mm (66.35mm) forged piston kit is designed for Husaberg TE 250 models from 2011 to 2018. Engineered for strength and precision, this piston ensures efficient heat transfer to the cylinder walls, providing uniform expansion and reducing localized pressure. The elliptical design distributes thrust loads evenly, preventing piston collapse. Manufactured in Germany, it meets high-quality standards for reliable performance.

Features

• Wossner forged piston for superior strength and durability
• Optimized heat transfer for improved combustion efficiency
• Elliptical design for uniform bearing surface and reduced localized pressure
• Precision-engineered to prevent piston collapse
• Made in Germany

Specifications

• Bore Size: 66.41mm (66.35mm)
• Oversize: +0.01mm
• Displacement: 249cc
• Stroke: 72.00mm
• Clearance: 0.06mm
• Compression Ratio: 2-stroke
• Compression Height: 38.00mm
• Lock Part Number: CW18
• Pin Part Number: WP033
• Ring Set Part Number: RSB6640 X 2
• Gasket Part Number: D2024
• Rod Part Number: P2023
• Theoretical Weight: Not specified

Vehicle Fitments

• Husaberg TE 250 (2011-2018)
