PISTON KIT 07-09 RMZ250 HC 77, FORGED WOSSNER 8672DB

Piston kit 77.01mm Bore 76.97 Wossner 8672DB (+0.01)

SUZUKI
RM-Z250 2007 - 2009,
(High compression)

• Wossner forged pistons are superior in strength and design.
• Engineered to provide the best possible path for combustion chamber heat transfer to cylinder walls.
• Elliptically designed to provide a more uniform bearing surface under piston heat expansion, eliminating localized pressure and distributing thrust loads more evenly, thereby preventing piston collapse.
• Made in Germany

Part No. 56-W305.B.WO (oro2u.com)
Wossner Piston Suzuki RM-Z250 77 mm Bore (PN# 8672DB)
Lock P/N CW16
Pin P/N WP070
Ring Set P/N 770XAS-2
Rod P/N P4004

Display (cm3) 249
Hub stroke (mm) 53.60
Clearance (mm) 0.04
Wossner compression Ratio: 13.90:1
OEM Compression ratio: 13.40:1
Dome volume (cm3) -2.50
Compression height (mm) 19.60
Theorectical weight (G)
