PISTON KIT 01-08 KTM50 SX, WOSSNER 8225DA FORGED MX 45030007000

KTM
SX50 2001 - 2008,
50 Mini Adventure 2002-2008,

• Wossner forged pistons are superior in strength and design.
• Engineered to provide the best possible path for combustion chamber heat transfer to cylinder walls.
• Elliptically designed to provide a more uniform bearing surface under piston heat expansion, eliminating localized pressure and distributing thrust loads more evenly, thereby preventing piston collapse.
• Made in Germany.

Part No. 56-W803.A.WO (phoenixmotos.com)
Wossner Piston KTM SX50 39.5 mm Bore (PN# 8225DA)
Lock P/N CW12
Pin P/N WP101
Ring Set P/N RSB3950

Display (cm3) 50
Hub stroke (mm) 40.00
Clearance (mm) 0.04
Wossner compression Ratio: 2 stroke
OEM Compression ratio: 2 stroke
Dome volume (cm3)
Compression height (mm) 21.60
Theorectical weight (G)

Cross reference numbers ONLY.
45030007000, 803M03950,

- 2007 KTM SX 50 - 2008 KTM SX 50
