PISTON 06-10 TC TE450 97.00, WOSSNER KIT 8651DB HUSQVARNA 8000A5471

Piston Kit 97.01mm Bore 96.97 Wossner 8651DB (+0.01)

HUSQVARNA
SMR 450 2006 - 2009,
TC 610 2006 - 2009,
TE 610 2006 - 2009,

• Wossner forged pistons are superior in strength and design.
• Engineered to provide the best possible path for combustion chamber heat transfer to cylinder walls.
• Elliptically designed to provide a more uniform bearing surface under piston heat expansion, eliminating localized pressure and distributing thrust loads more evenly, thereby preventing piston collapse.
• Made in Germany.

PART NO. 56-W146.WO.B (oro2u.com)
Wossner Piston Husqvarna TC450 97.01 mm Bore (PN# 8651DB)
Lock P/N CW20
Pin P/N WP038
Ring Set P/N 970ADS-2

Display (cm3) 449
Hub stroke (mm) 62.60
Clearance (mm) 0.05
Wossner compression Ratio:
OEM Compression ratio: -6.40
Dome volume (cm3) 25.50
Compression height (mm)
Theorectical weight (G)

Cross reference numbers ONLY.
8000A5471,
