HOSE FRONT BRAKE +2" DS650, DS650 2000-2007 FIR

This product is a 15-position circular automotive connector plug featuring dual contact sizes and a keyed design. It is constructed with a durable end cap and reduced-diameter seal, and is intended for vehicle applications requiring sealed multi-way electrical connections.

Features

• 15 contact positions
• Accommodates two contact sizes (size 12 and size 16)
• Socket contact type (female)
• Keyed design for proper mating orientation
• End cap design
• Reduced-diameter seal for improved environmental protection

Specifications

• Wire range: size 12 accepts 12–14AWG, size 16 accepts 14–20AWG
• Rated amperage: 25A for size12, 13A for size16
• Voltage rating: 250V
• Housing material: thermoplastic
• Operating temperature range: -55°C to +125°C
• Ingress protection when mated: IP68 and IP69K
• Dielectric withstand: leakage less than 2mA at 1,500VAC
• Insulation resistance: minimum 1,000MO at 25°C
• Seal material: silicone rubber
• Seal colours: red and green
• RoHS compliant
• Mating durability: 100 mating cycles
