Arrow Full system racing with Pro-Race "Dark" silencers Honda CB 650 R 2024–2026 71069PRN

Arrow full system racing with Pro-Race "Dark" silencers, manufacturer reference 71069PRN.

Specification

• Manufacturer part number: 71069PRN
• Silencer body material: stainless steel Dark
• End-cap material: stainless steel
• Silencer internal material: stainless steel
• Header material: stainless steel
• Mounting: welded mount
• DB-killer specified: No
• Oxygen sensor connection: Yes
• CO sensor connection: No

Arrow exhaust applications

Installation

Full exhaust system identified by Arrow reference 71069PRN. Follow the installation layout for the selected model and configuration.

• Arrow installation layout: Honda CB 650 R 2024–2026
• Arrow installation layout: Honda CBR 650 R 2024–2026

Manufacturer fitting instructions

• 3885542.PDF

Application-specific installation conditions

• Honda CB 650 R 2024/2026: Arrow warns that the racing collector configuration described in the notice may trigger a catalyst-monitoring ECU warning. Arrow recommends its A.R.D. device 11001EM for the specified configuration. Arrow technical notice
• Honda CBR 650 R 2024/2026: Arrow warns that the racing collector configuration described in the notice may trigger a catalyst-monitoring ECU warning. Arrow recommends its A.R.D. device 11001EM for the specified configuration. Arrow technical notice
