CRANKSHAFT MOUNTING TOOL KTM

SPECIAL CRANKSHAFT MOUNTING TOOL KTM.

- FITS KTM 300/250 SX, MXC, EXC, EGS
- Crankshaft mounting tool Specifically designed for KTM crankshaft assembly. .
- Fits crankshaft smoothly without damage to crankshaft or bearings.
- Overall length of tool is 146mm and constructed from carbon steel.
- Fitting face is O.D. 70mm x I.D. 43.5mm / 3.5mm depth.
- Long bolt end is Dia. M12 x 1.25mm with drive hole.
- oro2u products are a high quality Tools, Accessories and Part and carries our guarantee of your satisfaction.

Part No. 00-8100 (oro2u.com)

Instructions.
Sometimes the final assembly is done with a cold crankcase and a puller tool. This tool uses a long nut / stud to connect to the crankshaft end and a thick tube that allows you to pull the crankshaft through the main bearing without damage. By only pushing on the inner bearing race no damage to bearings will occur . Assembly is the same only you don't heat the crankcase. You pull the crankshaft through the bearing and this slides the two crankcases together.
