CONNECTING ROD KIT YAM DT100, RY-2008 558-11651-00 YAMAHA

Part No. 56-2944 (oro2u.com)
YAMAHA RX-100 / DT-100X W/W, 1972-1983,
YAMAHA DT100 LT2 LT3MX MX100 RS100,
Cross reference numbers ONLY. 558-11651-00-00

CONNECTING ROD SIZE PLEASE SEE DRAWING SIZE mm. A = 100, B = 14, C = 22, D = 15, E = 15, F = 49
PIN: DIA. 22 × L 49
WASHER: 34.5 × 22.2 × 1
BIG END BEARING: 22*28*14.8

SMALL END BEARING: 14*18*16.5
