CONNECTING ROD 97-02 KTM60/65, PSYCHIC MX-09041 46030015000
CONNECTING ROD 97-02 KTM60/65, PSYCHIC MX-09041 46030015000
Couldn't load pickup availability
KTM
SX60 / SX65 1998-2002,
CONNECTING CONROD ROD REBUILD KIT. PSYCHIC MX-09041
- Heavy-duty OE replacement connecting rods.
- Certified Chorme alloy steel provides superior strength.
- Crankpins are manufactured from hot-rolled ASTM steel and case hardened.
- Psychic Rods uses the latest in caged needle roller bearing designs for high rpm longevity.
- Thrust washers are manufactured from bronze phosphor and are silver coated.
- Rod assembly sold complete with rod, crankpin, crankpin bearing, top end bearing and thrust washers if need.
- Fully Compatible with after market and OE crankshafts.
- Material SNCM220,
SIZE | MM |
Centre 2 Centre | 88 |
Small End Bearing | 12x15x16.3 |
Small End Bore Ø | 15 |
Small End Width | 13 |
Big End Bearing | 18x24x14.8 |
Big End Bore Ø | 24 |
Big End Width | 14.90 |
Big End Pin Ø | 18 |
Big End Pin Length | 56 |
Washer Thickness | 1.00 |
Part No. 56-958.DR (oro2u.com)
Cross reference numbers ONLY.
MX-09041, HOTRODS 8625, 46030015000 ,
