CONNECTING ROD 87-06 YFS200, PSYCHIC AT-97307 YAMAHA ATV

- High-quality replacement kits are manufactured from hot-rolled ASTM 4115 and case-hardened.
- Rods are double-forged to improve grain flow and maintain dimensional consistency.
- Rods are also shot-peened and double-honed for superior strength under heavy loads.
- Small ends are drilled to supply extra lubrication and cooling to the wrist pin bearing, which is especially important when the piston crown is close to the wrist pin bearing
- Thrust washers and crank pin bearings are silver-coated for added lubricity.
- Kits sold complete with rod, crank pin, crank pin bearing, top end bearing, needle cage bearing, and thrust washers

Center To Center (mm): 110
Big End Bearing (mm):
Big End Bore (mm): 29
Big End Width (mm):
Big End Pin Diameter (mm): 22
Big End Pin Length (mm): 56.40
Small End Bearing (mm):
Small End Bore (mm): 21
Small End Width (mm):
Washer Thickness (mm): 1.00

Part No. 56-195.DR (phoenixmotos.com)

Cross reference numbers.
VESRAH VA-2009, WOSSNER P203, WISECO WPR170, PSYCHCIC AT- 97307, HOTROD 8144, 43G-11651-00-00,
